The 150x20mm UV LED Array with Forced Air Cooling is a system designed to fit UV LED Conveyors, consisting of a controller and UV LED Irradiation head, this device is available in 365nm, 385nm, 395nm & 405nm.
This UV LED Array comes with integrated forced air cooling and is suitable for conveyors with an LED Array that has a 150x20mm effective curing area.
Features;
- The integrated forced air cooling system ensures your array works as efficiently as possible, protecting the LED system and extending its useful life
- UV LED cold light source ensures your material’s composition won’t be harmed during curing process
- No preheating time needed, reach maximum light intensity instantly
- Power efficient and easy to install, use and control
- Eco-friendly, produces no ozone or mercury
- Lampshade protection makes it safer for workers
- Supports external signal input and triggering which makes it ideal for automatic or semi-automatic production lines
Technical Specifications
Available Wavelengths: 365nm, 385nm, 395nm, 405nm
365nm*:
- Optic Power: 4500mW/cm²
- Effective Curing Area: 150x20mm
- Electric Power: 396W
- Cooling Method: Forced Air Cooling
395nm*:
- Optic Power: 9000mW/cm²
- Effective Curing Area: 150x20mm
- Electric Power: 396W
- Cooling Method: Forced Air Cooling
*Technical Specifications available at the moment apply to the specified wavelengths.
Controller Technical Drawing
UV Array Head Technical Drawing
