WAC R2SD2T Volta 2″ Square LED Downlight Trim

Features

• Housing Sold Separately
• Finish: Black, Black/White, Copper Bronze, Haze, Haze/White, White
• Construction: Durable Die-cast self-flanged Aluminum construction
• Voltage: 120-277V
• Color Temperature: 2700K, 3000K
• Lumens: Up to 1390
• CBCP: Up to 5505
• CRI: 90
• ELV Dimming: 100-5%
• 0-10V Dimming: 100-0%
• Lutron Hi-Lume 1% Ecosystem Fade-to-Black option
• Beam Spread: 12°, 25°, 40°, 60°
• Rated Life: 50,000 Hours
• 1″ regressed lens for superior glare control
• Integral patterned tempered trim lens included standard
• Compatible with a wide range of accessories

Dimensions

• Aperture Size: 2″
• Width: 3.94″
• Height: 5.5“
• Ceiling Cutout: 3.56″ x 3.56″

• Ceiling Thickness: 0.5″ – 1.5″


Documents

• Spec Sheet
• Instruction Sheet
