WAC R4RD2L Volta 4.5″ Round LED Downlight Trimless

Features

• Housing Sold Separately
• Finish: Black, Copper Bronze, Haze, White
• Construction: Durable Die-cast Aluminum construction
• Voltage: 120-277V
• Color Temperature: 2700K, 3000K
• Lumens: Up to 3145
• CBCP: 11420
• CRI: 90
• ELV Dimming: 100-5%
• 0-10V Dimming: 100-0%
• Lutron Hi-Lume 1% Ecosystem Fade-to-Black option
• Beam Spread: 15°, 25°, 45°, 60°
• Rated Life: 50,000 Hours
• 2″ lens regress for superior glare control
• Field selectable light engine height for cut-off angle adjustment (30° – 34°) and accessory use
• Compatible with wide range of accessories

Dimensions

• Aperture Size: 4.5″
• Width: 4.5″
• Height: 6.38“
• Ceiling Cutout: 5.13″ Dia.

• Ceiling Thickness: 0.5″ – 1.5″


Documents

• Spec Sheet
• Instruction Sheet
